ANSI/TIA Category 6 Cable Type Unshielded Colour Black Type of conductor Solid | Stuck Built-in type of dust cover Nobody Mounting SL series faceplates and panels Installation Note The color is combined with black SL-style faceplates and surface mount boxes. Socket function Jack's upside-down face Outlet Type Standard Termination Blows, at least 200 times Completion Tool SL Completion Tool Completion type IDC Transmission standards ANSI/TIA-568.2-D | ISO/IEC 11801, Class E Electrical wiring T568A | T568B Cutout in the panel, recommended 14.78 x 20.07 mm (0.58 x 0.79 inches) Recommended panel thickness 1.6mm | 0.063 inches Height 16.13 mm | 0.635 inches Width 14.48 mm | 0.57 inches Depth 30.48 mm | 1.2 inches Compatible cable diameter, max 5.8mm | 0.228 inch Compatible insulated conductor diameter, max 1.45mm | 0.057inch Thickness of the contact coating 1.27 microns Compatible conductor gauge, solid 24–22 AWG Compatible conductor gauge, stranded 26–24 AWG Chan...
